ATEÏS

Digital, Intelligent, and Addressable Public Address and Voice Alarm System

About ATEÏS

ATEÏS specializes in life safety technology, focusing on 100% IP-based digital public address and voice alarm systems, digital controllers, speakers, and amplifiers. With over 3000 projects in India, their portfolio includes airports, metros, and stadiums.

ATEÏS
  • 100% IP-Based System: Ensures seamless communication and control over a robust network infrastructure.
  • Fully Digital System: Includes digital amplifiers for superior sound quality and reliability.
  • EN54-16 Certified Products with UL Listing: Approved and certified with international safety standards, guaranteeing performance and reliability.
  • Acoustic Design Support: Backed by EASE 4.2 software for precise and effective acoustic planning.
  • Proven Expertise: Over 5,000 landmark projects executed across India and Southeast Asia, including airports, metro stations, and stadiums.
  • IP-Based Flexibility: Easily scalable to accommodate future expansion needs.
  • BMS Integration: Features an on-board MODBUS port for seamless integration with Building Management Systems.
  • Commitment to Quality: No critical components sourced from China, ensuring top-notch product reliability.
  • Versatile Speaker Range: Offers a wide selection of speakers to suit diverse requirements and applications.
  • Cost-Effective Analog Option: Includes analog amplifiers as a budget-friendly alternative.
  • 8000 Zones Expansion Capacity: Scalable to handle extensive project requirements.
  • Simultaneous Audio Control: Manages and routes up to 48 audio channels over a dedicated network for efficient operation.
  • 100% System Redundancy: Provides complete redundancy at the controller, amplifier, and call station levels for uninterrupted performance.
  • Digital Noise Sensors: Automatically adjusts dB levels based on atmospheric sound, ensuring optimal audio clarity.
  • Faster Replacement Policy: Ensures minimal downtime with swift replacement solutions.

Solutions

BOUTIQUE
  • Open integration supports ip-pbx, voip, modbus tcp, and third-party systems like bms and fas.
  • Advanced dsp processing delivers superior audio with features like auto gain control and noise sensing.
  • Eco-friendly design minimizes power consumption during standby mode, reducing costs.
  • Speaker line monitoring detects circuit issues within 90 seconds for quick analysis.
  • Cost-effective installation with easy setup, dsp technology, and web-based controls.
  • Web-based monitoring allows remote control, zoning, scheduling, and logging without prior design effort.
  • Network redundancy ensures uninterrupted operation with redundant architecture and daisy chain setups.
BOUTIQUE
SYNERGIA
  • ATEÏS-Net ports for real time audio network with less than 1 ms*2 latency in star wired architecture or redundant loop
  • In case the amplifier fails, one of specified internal amplifier channel or an external amplifier can act as a backup amplifier
  • The 4 monitored remote controller ports can be wired in daisy-chain or in redundant loop using 2 ports
  • Embedded optional 48VDC battery backup power with charger or second AC power module
  • Slot A is used for analog telephone card or redundant remote network paging card for multiple paging consoles expansion
  • Dual Ethernet ports with auto detection, switch to secondary network if the primary one fails or its cable is disconnected
SYNERGIA
TERRACOM
  • Power supplied via PoE and/or 24VDC power adaptor
  • Paging with unicast, multicast, and broadcast
  • Protocols: TCP, UDP, SIP, RTP, IGMP, FTP, DHCP, ICECAST, HTTP, NTP, RTSP, MMS, and SNMP management
  • G.711, G.722, G.726, G.727, G.729, MP3 audio codec, and AAC+ decoder
  • Acoustic Echo Cancellation and Noise Reduction
  • Integrated graphic user software - TerraManager for monitoring and fault reporting of all system components
  • TerraServer management software for site redundancy
  • Event scheduler for audio programs, messages, and controls
  • Integration Automation with Home & Office Appliances via logic control for light, curtain, TV, or air conditioning on/ off via RS232, RS485, or Ethernet
  • Web browser interface for device control and monitoring
  • Logic input: pre-defined call, contact output activation, RS232 serial string generation, and alarm.
TERRACOM
IDA 8
  • Support a maximum up to 31 slave units in ATEÏS Local-Net
  • Up to 256 zones provision via ATEÏS Local-Net 32 bit DSP
  • Up to 8,192 zones provision via ATEÏS Global-Net
  • 2 modular I/O card-slots can be 8 IN, 8 OUT, 4IN4OUT
  • Handle up to 1000W wattage capacity (max.) per zone
  • 25/70/100V selectable outputs
  • 4 dedicated and monitored remote ports for paging consoles
  • 2 dedicated audio in and outputs for back-up amplifiers
  • Loudspeaker line surveillance (short, open, bad impedance)for speaker zone wiring (A/B)
  • Up to 100m by using STP CAT5/6 cable with NET-C1
  • Optional fiber-optic cards for links up to 20 km
  • 9 supervised control inputs and 8 control outputs
IDA 8
